Mitutoyo 100x LCD Plan APO NUV Objective - 378-751-4
Mitutoyo 100x LCD Plan APO NUV Objective - 378-751-4. This long working distance objective maintains focus from visible through the near-ultraviolet spectrum which makes it perfect for YAG-laser applications. This lens has cover glass thickness compensation for glass of 1.1mm thick.
| Specifications | |
|---|---|
| Type: | Infinity Corrected Brightfield |
| Wavelength: | Visible & NUV |
| Magnification: | 100x |
| Glass Thickness: | 1.1mm |
| N.A.: | 0.50 |
| Working Distance: | 10.03mm |
| Wavelength Range: | 355nm to 620nm |
| Focal Length: | 2mm |
| Resolving Power: | 0.6µm |
| Focal Depth: |
1.1µm |
| Field of View with Ø24 Eyepiece | Ø0.24 |
| Real Field of View with 1/2" Chip Camera | 0.05 x 0.06 |
| Thread Size: | M26 |
| Part Number: | 378-751-4 |
$3,385.80
Original: $11,286.00
-70%Mitutoyo 100x LCD Plan APO NUV Objective - 378-751-4—
$11,286.00
$3,385.80
Description
Mitutoyo 100x LCD Plan APO NUV Objective - 378-751-4. This long working distance objective maintains focus from visible through the near-ultraviolet spectrum which makes it perfect for YAG-laser applications. This lens has cover glass thickness compensation for glass of 1.1mm thick.
| Specifications | |
|---|---|
| Type: | Infinity Corrected Brightfield |
| Wavelength: | Visible & NUV |
| Magnification: | 100x |
| Glass Thickness: | 1.1mm |
| N.A.: | 0.50 |
| Working Distance: | 10.03mm |
| Wavelength Range: | 355nm to 620nm |
| Focal Length: | 2mm |
| Resolving Power: | 0.6µm |
| Focal Depth: |
1.1µm |
| Field of View with Ø24 Eyepiece | Ø0.24 |
| Real Field of View with 1/2" Chip Camera | 0.05 x 0.06 |
| Thread Size: | M26 |
| Part Number: | 378-751-4 |
